The 1290-00 Toroid Choke Series with QPL status offers a good range of ca. 30mm toroid Common Mode Chokes allowing for optimal space saving mounting on PCB.
Flux designs and manufactures in accordance with ESCC3201 and MIL-STD-981. The product represented in this data sheet is ESA Qualified (QPL) and will be delivered with an extensive ESCC data package containing test results by serial number. Products are manufactured, tested and inspected by ESA certified staff.
Flux designs and manufactures in accordance with ESCC3201 and MIL-STD-981. The product represented in this data sheet is ESA Qualified (QPL) and will be delivered with an extensive ESCC data package containing test results by serial number. Products are manufactured, tested and inspected by ESA certified staff.
ESCC320101301F12900008-1 Qualified part
Benefits
Quality Levels
Platformless
Simple construction
Flying leads
ESCC3201/013
MIL-STD-981 Class S
MIL-STD-981 Class B
HiRel/MIL IPC-A610 III
Included
Additional
ESA Qualified (QPL)
ESCC Inspection
ESCC Magnetic Sheet
ESCC Certificate
Test Data
X-Ray Inspection
Qualification test
Inductance Room Temp
±20%
Wire max. current
ESCC-Q-ST-30-11
Core Curie Temp
+140° C
Component specifications:
ESCC Part Number
Inductance
[μH]
Max current
[A]
